Chain-Level Power Without the Chain-Level Maintenance

If you're tired of lubricating, retensioning, and replacing roller chain, poly chain belts are the upgrade your drive has been waiting for. Gates Poly Chain GT Carbon belts deliver the power capacity of roller chain in a synchronous belt that never needs lubrication, never stretches into the scrap bin, and runs quieter than either chain or V-belt drives. V-Belt Supply stocks hundreds of sizes, ready to ship worldwide.

What Makes a Poly Chain Belt Different

Unlike a rubber timing belt, a poly chain GT carbon belt is built from a polyurethane body reinforced with carbon fiber tensile cords. That construction is what allows a narrow belt to carry loads that would normally require roller chain or multiple V-belts:

  • Carbon fiber cords provide high strength with virtually zero stretch, so drives hold their tension for the life of the belt
  • Polyurethane body resists abrasion, most chemicals, and moisture; no rust, no lube, no mess
  • Curvilinear tooth profile engages sprockets smoothly for quiet operation and precise, slip-free power transmission
  • Narrow widths transmit more power per inch than V-belts, allowing lighter, more compact drive designs

The result: poly chain belt drives commonly outlast roller chain many times over while eliminating lubrication and retensioning from your maintenance schedule entirely.

Poly Chain Belts section 2 image

Where They Excel

Gates poly chain belts are the go-to choice for low-speed, high-torque applications across the industries we serve every day: mining and aggregates, oil and gas, forestry, recycling, agriculture, and general manufacturing. Typical drives include bucket elevators, conveyors, crushers, mixers, pumps, and machine tools. For environments where static is a concern, the Poly Chain Carbon Volt series offers a non-conductive option that carries no static charge.

Poly Chain Belts section 4 image

How to Order the Right Belt

Every poly chain belt is identified by a simple part number that reads pitch, length, and width. For example, 8MGT-720-36 is an 8mm pitch belt, 720mm pitch length, 36mm wide. The three common pitches are:

  • 5MGT – compact, lighter-duty drives
  • 8MGT – the workhorse pitch for most industrial applications
  • 14MGT – heavy-duty, high-torque drives

To find your belt, search the part number with no spaces, dashes, or quotes. Replacing roller chain or a V-belt drive instead? Our team can help you spec the conversion. And if you have a worn belt with unreadable markings, send us the sprocket count and shaft details; we cross-reference Gates poly chain GT carbon belt numbers daily and will confirm the right size before you order.

One note for new installations: poly chain belts require matching Poly Chain sprockets. They are not interchangeable with standard timing belt pulleys, so verify your hardware when converting a drive.

For Shops, Distributors, and Maintenance Departments

If you stock belts or maintain equipment year-round, a V-Belt Supply commercial account gives you volume discounts, a dedicated account manager, and fast reordering on the sizes you use most. From a single belt to a full stockroom program, we keep your drives covered.

Browse the full selection above, or call us at (888) 291-5450, and our belt team will track down exactly what you need.
