8V/8VX Groove Sheaves Cross Reference

Below is a full cross reference and fitment table for 8V/8VX Groove Sheaves Cross Reference. If you have any questions, please feel free to call one of our Procurement Specialists at (888) 291-5450 or email us at [email protected].

TB Woods Part #	Outside Diameter	Bore Size	Martin Part #	Master Drive Part #	Browning Part #	Dodge Part #	Grainger Part Number #
8V1254	12.5	F	4 8V 125 F	48V125F	4/8V125F	4/8V12.5F	N/A
8V1255	12.5	F	5 8V 125 F	58V125F	5/8V125F	5/8V12.5F	N/A
8V1256	12.5	F	6 8V 125 F	68V125F	6/8V125F	6/8V12.5F	N/A
8V1258	12.5	J	8 8V 125 J	88V125J	8/8V125J	8/8V12.5J	N/A
8V12510	12.5	J	10 8V 125 J	108V125J	10/8V125J	10/8V12.5J	N/A
8V12512	12.5	M	12 8V 125 M	128V125M	12/8V125M	12/8V12.5M	N/A
8V1324	13.2	F	4 8V 132 F	48V132F	4/8V132F	4/8V13.2F	N/A
8V1325	13.2	F	5 8V 132 F	58V132F	5/8V132F	5/8V13.2F	N/A
8V1326	13.2	F	6 8V 132 F	68V132F	6/8V132F	6/8V13.2F	N/A
8V1328	13.2	J	8 8V 132 J	88V132J	8/8V132J	8/8V13.2J	N/A
8V13210	13.2	J	10 8V 132 J	108V132J	10/8V132J	10/8V13.2J	N/A
8V13212	13.2	M	12 8V 132 M	128V132M	12/8V132M	12/8V13.2M	N/A
8V1404	14.0	F	4 8V 140 F	48V140F	4/8V140F	4/8V14.0F	N/A
8V1405	14.0	F	5 8V 140 F	58V140F	5/8V140F	5/8V14.0F	N/A
8V1406	14.0	F	6 8V 140 F	68V140F	6/8V140F	6/8V14.0F	N/A
8V1408	14.0	J	8 8V 140 J	88V140J	8/8V140J	8/8V14.0J	N/A
8V14010	14.0	J	10 8V 140 J	108V140J	10/8V140J	10/8V14.0J	N/A
8V14012	14.0	M	12 8V 140 M	128V140M	12/8V140M	12/8V14.0M	N/A
8V1504	15.0	F	4 8V 150 F	48V150F	4/8V150F	4/8V15.0F	N/A
8V1505	15.0	F	5 8V 150 F	58V150F	5/8V150F	5/8V15.0F	N/A
8V1506	15.0	J	6 8V 150 J	68V150J	6/8V150J	6/8V15.0J	N/A
8V1508	15.0	J	8 8V 150 J	88V150J	8/8V150J	8/8V15.0J	N/A
8V15010	15.0	M	10 8V 150 M	108V150M	10/8V150M	10/8V15.0M	N/A
8V15012	15.0	M	12 8V 150 M	128V150M	12/8V150M	12/8V15.0M	N/A
8V1604	16.0	F	4 8V 160 F	48V160F	4/8V160F	4/8V16.0F	N/A
8V1605	16.0	F	5 8V 160 F	58V160F	5/8V160F	5/8V16.0F	N/A
8V1606	16.0	J	6 8V 160 J	68V160J	6/8V160J	6/8V16.0J	N/A
8V1608	16.0	J	8 8V 160 J	88V160J	8/8V160J	8/8V16.0J	N/A
8V16010	16.0	M	10 8V 160 M	108V160M	10/8V160M	10/8V16.0M	N/A
8V16012	16.0	M	12 8V 160 M	128V160M	12/8V160M	12/8V16.0M	N/A
8V1704	17.0	F	4 8V 170 F	48V170F	4/8V170F	4/8V17.0F	N/A
8V1705	17.0	J	5 8V 170 J	58V170J	5/8V170J	5/8V17.0J	N/A
8V1706	17.0	J	6 8V 170 J	68V170J	6/8V170J	6/8V17.0J	N/A
8V1708	17.0	M	8 8V 170 M	88V170M	8/8V170M	8/8V17.0M	N/A
8V17010	17.0	M	10 8V 170 M	108V170M	10/8V170M	10/8V17.0M	N/A
8V17012	17.0	M	12 8V 170 M	128V170M	12/8V170M	12/8V17.0M	N/A
8V1804	18.0	F	4 8V 180 F	48V180F	4/8V180F	4/8V18.0F	N/A
8V1805	18.0	J	5 8V 180 J	58V180J	5/8V180J	5/8V18.0J	N/A
8V1806	18.0	J	6 8V 180 J	68V180J	6/8V180J	6/8V18.0J	N/A
8V1808	18.0	M	8 8V 180 M	88V180M	8/8V180M	8/8V18.0M	N/A
8V18010	18.0	M	10 8V 180 M	108V180M	10/8V180M	10/8V18.0M	N/A
8V18012	18.0	M	12 8V 180 M	128V180M	12/8V180M	12/8V18.0M	N/A
8V1904	19.0	F	4 8V 190 F	48V190F	4/8V190F	4/8V19.0F	N/A
8V1905	19.0	J	5 8V 190 J	58V190J	5/8V190J	5/8V19.0J	N/A
8V1906	19.0	J	6 8V 190 J	68V190J	6/8V190J	6/8V19.0J	N/A
8V1908	19.0	M	8 8V 190 M	88V190M	8/8V190M	8/8V19.0M	N/A
8V19010	19.0	M	10 8V 190 M	108V190M	10/8V190M	10/8V19.0M	N/A
8V19012	19.0	N	12 8V 190 N	128V190N	12/8V190N	12/8V19.0N	N/A
8V2004	20.0	J	4 8V 200 J	48V200J	4/8V200J	4/8V20.0J	N/A
8V2005	20.0	J	5 8V 200 J	58V200J	5/8V200J	5/8V20.0J	N/A
8V2006	20.0	M	6 8V 200 M	68V200M	6/8V200M	6/8V20.0M	N/A
8V2008	20.0	M	8 8V 200 M	88V200M	8/8V200M	8/8V20.0M	N/A
8V20010	20.0	M	10 8V 200 M	108V200M	10/8V200M	10/8V20.0M	N/A
8V20012	20.0	N	12 8V 200 N	128V200N	12/8V200N	12/8V20.0N	N/A
8V2124	21.2	J	4 8V 212 J	48V212J	4/8V212J	4/8V21.2J	N/A
8V2125	21.2	J	5 8V 212 J	58V212J	5/8V212J	5/8V21.2J	N/A
8V2126	21.2	M	6 8V 212 M	68V212M	6/8V212M	6/8V21.2M	N/A
8V2128	21.2	M	8 8V 212 M	88V212M	8/8V212M	8/8V21.2M	N/A
8V21210	21.2	M	10 8V 212 M	108V212M	10/8V212M	10/8V21.2M	N/A
8V21212	21.2	N	12 8V 212 N	128V212N	12/8V212N	12/8V21.2N	N/A
8V2244	22.4	J	4 8V 224 J	48V224J	4/8V224J	4/8V22.4J	N/A
8V2245	22.4	M	5 8V 224 M	58V224M	5/8V224M	5/8V22.4M	N/A
8V2246	22.4	M	6 8V 224 M	68V224M	6/8V224M	6/8V22.4M	N/A
8V2248	22.4	M	8 8V 224 M	88V224M	8/8V224M	8/8V22.4M	N/A
8V22410	22.4	N	10 8V 224 N	108V224N	10/8V224N	10/8V22.4N	N/A
8V22412	22.4	N	12 8V 224 N	128V224N	12/8V224N	12/8V22.4N	N/A
8V2484	24.8	M	4 8V 248 M	48V248M	4/8V248M	4/8V24.8M	N/A
8V2485	24.8	M	5 8V 248 M	58V248M	5/8V248M	5/8V24.8M	N/A
8V2486	24.8	M	6 8V 248 M	68V248M	6/8V248M	6/8V24.8M	N/A
8V2488	24.8	N	8 8V 248 N	88V248N	8/8V248N	8/8V24.8N	N/A
8V24810	24.8	N	10 8V 248 N	108V248N	10/8V248N	10/8V24.8N	N/A
8V24812	24.8	N	12 8V 248 N	128V248N	12/8V248N	12/8V24.8N	N/A
8V3004	30.0	M	4 8V 300 M	48V300M	4/8V300M	4/8V30.0M	N/A
8V3005	30.0	M	5 8V 300 M	58V300M	5/8V300M	5/8V30.0M	N/A
8V3006	30.0	M	6 8V 300 M	68V300M	6/8V300M	6/8V30.0M	N/A
8V3008	30.0	N	8 8V 300 N	88V300N	8/8V300N	8/8V30.0N	N/A
8V30010	30.0	N	10 8V 300 N	108V300N	10/8V300N	10/8V30.0N	N/A
8V30012	30.0	P	12 8V 300 P	128V300P	12/8V300P	12/8V30.0P	N/A
8V3554	35.5	M	4 8V 355 M	48V355M	4/8V355M	4/8V35.5M	N/A
8V3555	35.5	M	5 8V 355 M	58V355M	5/8V355M	5/8V35.5M	N/A
8V3556	35.5	N	6 8V 355 N	68V355N	6/8V355N	6/8V35.5N	N/A
8V3558	35.5	N	8 8V 355 N	88V355N	8/8V355N	8/8V35.5N	N/A
8V35510	35.5	P	10 8V 355 P	108V355P	10/8V355P	10/8V35.5P	N/A
8V35512	35.5	P	12 8V 355 P	128V355P	12/8V355P	12/8V35.5P	N/A
8V4004	40.0	M	4 8V 400 M	48V400M	4/8V400M	4/8V40.0M	N/A
8V4005	40.0	M	5 8V 400 M	58V400M	5/8V400M	5/8V40.0M	N/A
8V4006	40.0	N	6 8V 400 N	68V400N	6/8V400N	6/8V40.0N	N/A
8V4008	40.0	N	8 8V 400 N	88V400N	8/8V400N	8/8V40.0N	N/A
8V40010	40.0	P	10 8V 400 P	108V400P	10/8V400P	10/8V40.0P	N/A
8V40012	40.0	P	12 8V 400 P	128V400P	12/8V400P	12/8V40.0P	N/A
8V4454	44.5	M	4 8V 445 M	48V445M	4/8V445M	4/8V44.5M	N/A
8V4455	44.5	N	5 8V 445 N	58V445N	5/8V445N	5/8V44.5N	N/A
8V4456	44.5	N	6 8V 445 N	68V445N	6/8V445N	6/8V44.5N	N/A
8V4458	44.5	P	8 8V 445 P	88V445P	8/8V445P	8/8V44.5P	N/A
8V44510	44.5	P	10 8V 445 P	108V445P	10/8V445P	10/8V44.5P	N/A
8V44512	44.5	P	12 8V 445 P	128V445P	12/8V445P	12/8V44.5P	N/A
8V5304	53.0	M	4 8V 530 M	48V530M	4/8V530M	4/8V53.0M	N/A
8V5305	53.0	N	5 8V 530 N	58V530N	5/8V530N	5/8V53.0N	N/A
8V5306	53.0	N	6 8V 530 N	68V530N	6/8V530N	6/8V53.0N	N/A
8V5308	53.0	P	8 8V 530 P	88V530P	8/8V530P	8/8V53.0P	N/A
8V53010	53.0	P	10 8V 530 P	108V530P	10/8V530P	10/8V53.0P	N/A
8V53012	53.0	W	12 8V 530 W	128V530W	12/8V530W	12/8V53.0W	N/A
8V6306	63.0	P	6 8V 630 P	68V630P	6/8V630P	6/8V63.0P	N/A
8V6308	63.0	P	8 8V 630 P	88V630P	8/8V630P	8/8V63.0P	N/A
8V63010	63.0	W	10 8V 630 W	108V630W	10/8V630W	10/8V63.0W	N/A
8V63012	63.0	W	12 8V 630 W	128V630W	12/8V630W	12/8V63.0W	N/A
8V7106	71.0	P	6 8V 710 P	68V710P	6/8V710P	6/8V71.0P	N/A
8V7108	71.0	W	8 8V 710 W	88V710W	8/8V710W	8/8V71.0W	N/A
8V71010	71.0	W	10 8V 710 W	108V710W	10/8V710W	10/8V71.0W	N/A
8V71012	71.0	W	12 8V 710 W	128V710W	12/8V710W	12/8V71.0W	N/A
