C Groove Sheaves Cross Reference

Below is a full cross reference and fitment table for C Groove Sheaves. If you have any questions, please feel free to call one of our Procurement Specialists at (888) 291-5450 or email us at [email protected].

TB Woods Part #	Outside Diameter	Bore Size	Martin Part #	Master Drive Part #	Browning Part #	Dodge Part #	Grainger Part Number #
606C	6.6	SF	6 C 60 SF	6C60SF	6C60SF	6C6.0SF	N/A
706C	7.4	SF	6 C 70 SF	6C70SF	6C70SF	6C7.0SF	N/A
707C	7.4	SF	7 C 70 SF	7C70SF	7C70SF	7C7.0SF	N/A
708C	7.4	SF	8 C 70 SF	8C70SF	8C70SF	8C7.0SF	N/A
756C	7.9	SF	6 C 75 SF	6C75SF	6C75SF	6C7.5SF	N/A
8010C	8.4	E	10 C 80 E	10C80E	10C80E	10C8.0E	N/A
806C	8.4	E	6 C 80 E	6C80E	6C80E	6C8.0E	5KYN0
807C	8.4	E	7 C 80 E	7C80E	7C80E	7C8.0E	N/A
808C	8.4	E	8 C 80 E	8C80E	8C80E	8C8.0E	N/A
809C	8.4	E	9 C 80 E	9C80E	9C80E	9C8.0E	N/A
8510C	8.9	E	10 C 85 E	10C85E	10C85E	10C8.5E	N/A
856C	8.9	E	6 C 85 E	6C85E	6C85E	6C8.5E	N/A
857C	8.9	E	7 C 85 E	7C85E	7C85E	7C8.5E	N/A
858C	8.9	E	8 C 85 E	8C85E	8C85E	8C8.5E	N/A
859C	8.9	E	9 C 85 E	9C85E	9C85E	9C8.5E	N/A
9010C	9.4	J	10 C 90 J	10C90J	10C90J	10C9.0J	N/A
906C	9.4	F	6 C 90 F	6C90F	6C90F	6C9.0F	5YKN9
907C	9.4	F	7 C 90 F	7C90F	7C90F	7C9.0F	N/A
908C	9.4	F	8 C 90 F	8C90F	8C90F	8C9.0F	N/A
909C	9.4	J	9 C 90 J	9C90J	9C90J	9C9.0J	N/A
9510C	9.9	J	10 C 95 J	10C95J	10C95J	10C9.5J	N/A
956C	9.9	F	6 C 95 F	6C95F	6C95F	6C9.5F	5YKP6
957C	9.9	F	7 C 95 F	7C95F	7C95F	7C9.5F	N/A
958C	9.9	F	8 C 95 F	8C95F	8C95F	8C9.5F	N/A
959C	9.9	J	9 C 95 J	9C95J	9C95J	9C9.5J	N/A
10010C	10.4	J	10 C 100 J	10C100J	10C100J	10C10.0 J	N/A
1006C	10.4	F	6 C 100 F	6C100F	6C100F	6C10.0 F	5YJZ7
1007C	10.4	F	7 C 100 F	7C100F	7C100F	7C10.0 F	N/A
1008C	10.4	F	8 C 100 F	8C100F	8C100F	8C10.0 F	N/A
1009C	10.4	J	9 C 100 J	9C100J	9C100J	9C10.0 J	N/A
10510C	10.9	J	10 C 105 J	10C105J	10C105J	10C10.5J	N/A
1056C	10.9	F	6 C 105 F	6C105F	6C105F	6C10.5F	N/A
1057C	10.9	F	7 C 105 F	7C105F	7C105F	7C10.5F	N/A
1058C	10.9	F	8 C 105 F	8C105F	8C105F	8C10.5F	N/A
1059C	10.9	J	9 C 105 J	9C105J	9C105J	9C10.5J	N/A
11010C	11.4	J	10 C 110 J	10C110J	10C110J	10C11.0J	N/A
1106C	11.4	F	6 C 110 F	6C110F	6C110F	6C11.0F	5YKA4
1107C	11.4	F	7 C 110 F	7C110F	7C110F	7C11.0F	N/A
1108C	11.4	F	8 C 110 F	8C110F	8C110F	8C11.0F	N/A
1109C	11.4	J	9 C 110 J	9C110J	9C110J	9C11.0J	N/A
12010C	12.4	J	10 C 120 J	10C120J	10C120J	10C12.0J	N/A
1206C	12.4	F	6 C 120 F	6C120F	6C120F	6C12.0F	5YKA7
1207C	12.4	F	7 C 120 F	7C120F	7C120F	7C12.0F	N/A
1208C	12.4	F	8 C 120 F	8C120F	8C120F	8C12.0F	N/A
1209C	12.4	J	9 C 120 J	9C120J	9C120J	9C12.0J	N/A
13010C	13.4	J	10 C 130 J	10C130J	10C130J	10C13.0J	N/A
1306C	13.4	F	6 C 130 F	6C130F	6C130F	6C13.0F	N/A
1307C	13.4	F	7 C 130 F	7C130F	7C130F	7C13.0F	N/A
1308C	13.4	F	8 C 130 F	8C130F	8C130F	8C13.0F	N/A
1309C	13.4	J	9 C 130 J	9C130J	9C130J	9C13.0J	N/A
14010C	14.4	J	10 C 140 J	10C140J	10C140J	10C14.0J	N/A
1406C	14.4	F	6 C 140 F	6C140F	6C140F	6C14.0F	N/A
1407C	14.4	F	7 C 140 F	7C140F	7C140F	7C14.0F	N/A
1408C	14.4	F	8 C 140 F	8C140F	8C140F	8C14.0F	N/A
1409C	14.4	J	9 C 140 J	9C140J	9C140J	9C14.0J	N/A
16010C	16.4	J	10 C 160 J	10C160J	10C160J	10C16.0J	N/A
1606C	16.4	F	6 C 160 F	6C160F	6C160F	6C16.0F	N/A
1607C	16.4	F	7 C 160 F	7C160F	7C160F	7C16.0F	N/A
1608C	16.4	F	8 C 160 F	8C160F	8C160F	8C16.0F	N/A
1609C	16.4	J	9 C 160 J	9C160J	9C160J	9C16.0J	N/A
18010C	18.4	J	10 C 180 J	10C180J	10C180J	10C18.0J	N/A
1806C	18.4	F	6 C 180 F	6C180F	6C180F	6C18.0F	N/A
1807C	18.4	F	7 C 180 F	7C180F	7C180F	7C18.0F	N/A
1808C	18.4	F	8 C 180 F	8C180F	8C180F	8C18.0F	N/A
1809C	18.4	J	9 C 180 J	9C180J	9C180J	9C18.0J	N/A
20010C	20.4	J	10 C 200 J	10C200J	10C200J	10C20.0J	N/A
2006C	20.4	F	6 C 200 F	6C200F	6C200F	6C20.0F	N/A
2007C	20.4	J	7 C 200 J	7C200J	7C200J	7C20.0J	N/A
2008C	20.4	J	8 C 200 J	8C200J	8C200J	8C20.0J	N/A
2009C	20.4	J	9 C 200 J	9C200J	9C200J	9C20.0J	N/A
2405C	24.4	F	5 C 240 F	5C240F	5C240F	5C24.0F	N/A
2406C	24.4	F	6 C 240 F	6C240F	6C240F	6C24.0F	N/A
2407C	24.4	J	7 C 240 J	7C240J	7C240J	7C24.0J	N/A
2408C	24.4	J	8 C 240 J	8C240J	8C240J	8C24.0J	N/A
2409C	24.4	J	9 C 240 J	9C240J	9C240J	9C24.0J	N/A
2705C	27.4	F	5 C 270 F	5C270F	5C270F	5C27.0F	N/A
2706C	27.4	J	6 C 270 J	6C270J	6C270J	6C27.0J	N/A
2707C	27.4	J	7 C 270 J	7C270J	7C270J	7C27.0J	N/A
2708C	27.4	J	8 C 270 J	8C270J	8C270J	8C27.0J	N/A
2709C	27.4	J	9 C 270 J	9C270J	9C270J	9C27.0J	N/A
3005C	30.4	F	5 C 300 F	5C300F	5C300F	5C30.0F	N/A
3006C	30.4	J	6 C 300 J	6C300J	6C300J	6C30.0J	N/A
3007C	30.4	J	7 C 300 J	7C300J	7C300J	7C30.0J	N/A
3008C	30.4	J	8 C 300 J	8C300J	8C300J	8C30.0J	N/A
3009C	30.4	M	9 C 300 M	9C300M	9C300M	9C30.0M	N/A
3605C	36.4	J	5 C 360 J	5C360J	5C360J	5C36.0J	N/A
3606C	36.4	J	6 C 360 J	6C360J	6C360J	6C36.0J	N/A
3607C	36.4	J	7 C 360 J	7C360J	7C360J	7C36.0J	N/A
3608C	36.4	M	8 C 360 M	8C360M	8C360M	8C36.0M	N/A
3609C	36.4	M	9 C 360 M	9C360M	9C360M	9C36.0M	N/A
4405C	44.4	J	5 C 440 J	5C440J	5C440J	5C44.0J	N/A
4406C	44.4	J	6 C 440 J	6C440J	6C440J	6C44.0J	N/A
4407C	44.4	M	7 C 440 M	7C440M	7C440M	7C44.0M	N/A
4408C	44.4	M	8 C 440 M	8C440M	8C440M	8C44.0M	N/A
4409C	44.4	M	9 C 440 M	9C440M	9C440M	9C44.0M	N/A
5005C	50.4	J	5 C 500 J	5C500J	5C500J	5C50.0J	N/A
5006C	50.4	M	6 C 500 M	6C500M	6C500M	6C50.0M	N/A
5007C	50.4	M	7 C 500 M	7C500M	7C500M	7C50.0M	N/A
5008C	50.4	M	8 C 500 M	8C500M	8C500M	8C50.0M	N/A
5009C	50.4	M	9 C 500 M	9C500M	9C500M	9C50.0M	N/A
